GE JGAS02 owner manual Using the oven

Page 10

Instructions

Using the oven.

Throughout this manual, features and appearance may vary from your model.

Instructions Safety

OVEN

TEMP





OFF









2







6







0







3







0







0

I





3

L



5



O

0



R





B

4







0





005

0





4





05





Oven Control

Your oven is controlled by an OVEN TEMP knob. It can take up to 90 seconds before the flame comes on.

After the oven reaches the selected temperature, the oven burner maintains the selected temperature.

Oven Lighting Instructions for Standing Pilot Models

The standing oven pilot must be lit initially.

To light the oven pilot:

Be sure the OVEN TEMP knob is in the OFF position.

Open the oven door and remove the oven bottom. See the Removable Oven Bottom section in Care and Cleaning.

Find the oven pilot port at the back of the oven.

To light the oven pilot, push in

and hold the OVEN TEMP knob while lighting the pilot with a long match or match in a match holder. Once the oven pilot is lit, continue holding the OVEN TEMP knob in for one minute before releasing.

Power Outage—Standing Pilot Models

An electrical power failure will not affect the standing oven pilot.

Power Outage—Electric Ignition Models

Tips Installation Instructions Care and Cleaning Operating

CAUTION: Do not make any attempt to operate the electric ignition oven during an electric power failure. The oven or broiler cannot be lit during a power failure. Gas will not flow unless the glow bar is hot.

If the oven is in use when a power failure occurs, the oven burner shuts off and cannot be re-lit until power is restored. This is because the flow of gas is automatically stopped and will not resume when power is restored until the glow bar has reached operating temperature.

Consumer Support Troubleshooting

Bump

10

Oven Shelves

The shelves are designed with stop-locks so when placed correctly on the shelf supports, they will stop before coming completely out of the oven and will not tilt when you are removing food from them or placing food on them.

When placing cookware on a shelf, pull the shelf out to the bump on the shelf support. Place the cookware on the shelf, then slide the shelf back into the oven. This will eliminate reaching into the hot oven.

To remove the shelves from the oven, pull them toward you, tilt front end upward and pull them out.

To replace, place shelf on shelf support with stop-locks (curved extension of shelf) facing up and toward back of oven. Tilt up front and push shelf toward back of oven until it goes past the bump on the shelf support. Then lower front of shelf and push it all the way back.
