Acer M5810 manual Keyboard, Power Supply

Error Symptom	Action/FRU
Video memory test failed.Video adapter failed.	1.Remove all non-factory-installed cards.
	2.Load default settings (if screen is readable).
	3.Main board
Display problem:	1.Monitor signal connection/cable.
-Incorrect colors	2.Monitor
No high intensity	3.Video adapter card
Missing, broken, or incorrect characters	4.Main board
Blank monitor (dark)
Blank monitor (bright)
Distorted image
Unreadable monitor
Other monitor problems
Display changing colors.	1.Monitor signal connection/cable
	2.Monitor
	3.Main board
Display problem not listed above (including blank or	1.”Monitor"
illegible monitor).	2.Load default settings (if screen is readable).
	3.Main board

Parallel/Serial Ports
Execute “Load BIOS Default Settings” in BIOS Setup to confirm ports presence before diagnosing any
parallel/serial ports problems.
Serial or parallel port loop-back test failed.	1.Make sure that the LPT# or COM# you test is the
	same as the setting in BIOS Setup.
	2.Loop-back.
	3.Main board
Printing failed.	1.Ensure the printer driver is properly installed.
	Refer to the printer service manual.
	2.Printer.
	3.Printer cable.
	4.Main board.
Printer problems.	1.Refer to the service manual for the printer.
Keyboard
Some or all keys on keyboard do not work.	1.Keyboard
Power Supply
Pressing power switch does not turn off system.	1.Ensure the Soft-off by PWR-BTTN. in BIOS Setup
(Only unplugging the power cord from electrical	of Power Management is not set to Instant-off.
outlet can turn off the system.)	2.Power switch cable assembly
Pressing power switch does not turn on the system.	1.Ensure the power override switch (situated at the
	back of the machine, just above the connector for
	the power cable) is not set to OFF.
	2.Power switch cable assembly.

Chapter 4 56
