Power On By PS/2 Mouse [Disabled]

When set to [Enabled], this parameter allows you to use the PS/2 mouse to turn on the system. This feature requires an ATX power supply that provides at least 1A on the +5VSB lead. Configuration options: [Disabled] [Enabled]

4.6.6Hardware Monitor



BIOS SETUP UTILITY





Power



Hardware Monitor







CPU Temperature

[59.5ºC/139ºF]

MB Temperature

[32ºC/89.5ºF]

CPU Fan Speed (RPM)

[4218 RPM]

CPU Q-Fan Control

[Disabled]

Chassis Fan 1 Speed

[N/A]

Chassis Fan 2 Speed

[N/A]

Chassis Fan 3 Speed

[N/A]

Chassis Q-Fan Control

[Disabled]

OPT Q-Fan an Temperature







Voltage Warning Message

[Enabled]

VCORE Voltage

: 1.320 V

FSB Termination Voltage

: 1.232 V

NB Vcore

: 1.280 V

DDR Voltage

: 1.936 V

DDR Termination Voltage

: 0.960 V

SB Chipset Voltage

: 1.072 V

CPU Temperature

Select Screen

Select Item

+- Change Field

F1 General Help

F10 Save and Exit

ESC Exit

v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.

CPU Temperature [xxxºC/xxxºF]

MB Temperature [xxxºC/xxxºF]

The onboard hardware monitor automatically detects and displays the motherboard and CPU temperatures. Select [Ignored] if you do not wish to display the detected temperatures.

CPU Fan Speed [xxxxRPM] or [Ignored] / [N/A]

The onboard hardware monitor automatically detects and displays the CPU fan speed in rotations per minute (RPM). If the fan is not connected to the motherboard, the field shows N/A.

CPU Q-Fan Control [Disabled]

Allows you to enable or disable the CPU Q-Fan controller.

Configuration options: [Disabled] [Enabled]

The CPU Fan Profile item appears when you enable the CPU Q-Fan Control feature.

ASUS Commando

4-29
