4.5.3CPU Configuration

The items in this menu show the CPU-related information that the BIOS automatically detects.

BIOS SETUP UTILITY

Advanced

Configure Advanced CPU settings

Module Version: 3C.0E

Manufacturer:Intel

Brand String:Genuine Intel(R) CPU 3.20GHz

Frequency

:3.2GHz



FSB Speed

:533 MHz



Cache L1

:16 KB



Cache L2

:256 KB



Ratio Status:Unlocked (Max:24, Min:14)

Ratio Actual Value: 24



CPUID

:F41



Modify Ratio Support

[Disabled]

C1E Support



[Enabled]

Max CPUID Value Limit:

[Disabled]

Vanderpool Technology

[Enabled]

CPU TM function:

[Enabled]

Execute Disable Bit

[Enabled]

Hyper Threading Technology

[Enabled]

Intel(R) SpeedStep(tm) Tech.

[Disabled]

Options

Disabled

Enabled

Select Screen

Select Item

+- Change Option

F1 General Help

F10 Save and Exit

ESC Exit

v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.

Modify Ratio Support [Disabled]

Configuration options: [Disabled] [Enabled]

The following item appears when the item Modify Ratio Support is set to [Enabled].

Ratio CMOS Setting: [24]

C1E Support [Enabled]

Allows you to enable or disable C1E Support.

Configuration options: [Enabled] [Disabled]

Max CPUID Value Limit [Disabled]

Setting this item to [Enabled] allows legacy operating systems to boot even without support for CPUs with extended CPUID functions.

Configuration options: [Disabled] [Enabled]

Vanderpool Technology [Enabled]

Configuration options: [Enabled] [Disabled]

CPU TM function [Enabled]

Configuration options: [Disabled] [Enabled]

ASUS Commando

4-23
