Figure 4-8shows an example of drive hardware that can be installed in the Dell Precision 610 mini tower system. Refer to this figure when you perform any of the procedures in the following subsections.

DC power/interface cable

DSKT2 connector

3.5-inch diskette drive housing

externally accessible drive bays

hard-disk drive bracket

)LJXUH

EIDE cable

primary EIDE connector (IDE1)

secondary EIDE connector (IDE2)
