Removing and Replacing Parts 4-2 3
',00V
To remove a DIMM, follow these steps:
To replace a DIMM, press the DIMM fully into the socket (see step 1 of
Figure 4-20) while closing the securing clips to lock the DIMM into the socket
(see step 2 of Figure 4-20).
securing clips (2)
DIMM
securing clips (2)
1.
2.
DIMM
