To remove the diskette drive, complete the following steps:
1.Prepare the computer for disassembly.
2.Remove the palmrest assembly.
3.Remove the keyboard and heatspreader.
4.Remove the hard drive.
5.Remove the Upper CPU cover.
6.Remove the charger board.
7.Remove
the speakers.
8.Disconnect the diskette drive data cable from the system board by pulling out the cable lock lip about 1 or 2 mm at each end, then removing the cable .
Next Step
