Removing the System Board (continued)
Check that all cables have IMPORTANT: been disconnected from
the system board before continuing.
18. Tilt the system board up towards the middle of the unit.
19. Hold in the PCMCIA eject lever while carefully rotating the system board clockwise in a horizontal plane and manipulating it out of the chassis.
To replace the system board, reverse the previous steps.
