1. Motor Type
You should set the Motor Type before Motor Antenna Setting.
1.Select Motor Type from Motor Antenna, and press the OK or
button.
2.Set LNB Frequency.
•Select LNB Frequency using the button, and press the
OK or
button.
•Enter LNB Frequency value using the NUMERICAL (0~9) buttons.
•When completing entering LNB Frequency, press the OK button.
3.Set LNB Voltage
Refer to Installaion - Antenna Setting - LNB Voltage. The distance between antenna and receiver is 30 m instead of 60 m.
4.Select Motor Type using the button, and press the OK
or
button to select Motor Type.
DiSEqC1.2 General Motor Antenna using DiSEqC 1.2
USALS | Motor Antenna using USALS |
5.Set My Longitude.
•Select My Longitude using the button, and press the
OK or
button to select Motor Type.
•Enter Longitude value using the NUMERICAL (0~9) buttons.
•Set East/West using the button.
•When completing setting, press the OK button.
6.Set My Latitude.
•Select My Latitude using the button, and press the OK
or
button.
•Enter Latitude value using the NUMERICAL (0~9) buttons.
•Set North/South using the button
•When completing setting, press the OK button.
**
**
**
**
**
