Manual Update

You can perform Manual Update only if you know which satellite has new software and the Transponder information correctly.

1.Select Manual from Software Update Menu screen using the

button, and press the OK or button.

Select the the Satellite which provides update software. Satellite list contains the satellites that have been set to Enable in Installation -Antenna Setting-Satellite Alternative menu. For unlisted satellite, start with Antenna Setting.

2.Enter Transponder Frequency in which updated software is provided.

3.Enter Polarisation value.

4.Select Symbol Rate value. If it is not found in the List, select User Define and enter manually.

5.Select FEC value.

Note: How to setting Satellite and Transponder for Manual Update

Sites is the same as how to edit User Define Transponder data in

Manual Search. Refer to Manual Search.

6.Select Search and Press the OK button to search software.

7.It is displayed whether or not New Software exists.

If new software does not exist, press the OK button to return to the Manual Update Menu.

8.Select Yes and press the OK button to start updating. Select

No and press the OK button to return to the previous menu.

9.Performs Software Update. Please wait until it is completed.

10.When completing the software update, the product is automatically powered off and on again.

**

**

**

**

**

GB 67

**

**

**

**

**
