62 EN | SYSTEM CONNECTIONS |
Connection To A Personal Computer
[A] Using USB cable
Connector | To USB connector | |
Cover* | ||
| ||
| USB cable (provided) | |
To USB | PC | |
|
[B] Using DV cable | OR |
|
Connector |
| To DV |
Cover* | DV cable | |
| (optional) | connector |
| Core filter | Core filter |
|
| PC with DV |
To DV IN/OUT |
| connector |
|
|
*When connecting the cable, open the cover.
[A] Using USB cable
It is possible to do the following things:
●Transfer still images stored on a memory card to a PC.
●Transfer still/moving images recorded on a tape to a PC.
●Capture still/moving images in
●Use this camcorder as a WebCam. ( pg. 63)
[B] Using DV cable
It is also possible to transfer still/moving images to a PC with a DV connector by using the provided software, software equipped with the PC or commercially available software.
NOTES:
●Refer to “SOFTWARE INSTALLATION AND USB CONNECTION GUIDE” for the installation of the bundled software and drivers.
●The software operation manual is provided as PDF file on the
●It is recommended to use the AC Power Adapter/ Charger as the power supply instead of the battery pack. ( pg. 11)
●Never connect the USB cable and the DV cable simultaneously to the camcorder. Connect only the cable you wish to use to the camcorder.
●When using a DV cable, be sure to use the optional JVC
●If the PC connected to the camcorder via the USB cable is not powered, the camcorder does not enter the USB mode.
●The date/time information cannot be captured into the PC.
●Refer to the instruction manuals of the PC and Software.
●The still images can also be transferred to a PC with a DV
●The system may not work properly depending on the PC or capture board you are using.
“USB MODE” and/or “ACCESSING FILES” appears on the LCD monitor while the PC is accessing data in the camcorder or the camcorder is transferring a file to the PC.
NEVER disconnect the USB cable while
“ACCESSING FILES” is displayed on the LCD monitor since this can result in product damage.
