Page 41

Creative Photography (Scene Modes)

The camera offers a choice of “scene” modes. Choosing a scene mode automatically optimizes settings to suit the selected scene, making creative photography as simple as selecting a mode, framing a picture, and shooting as described on pages 21–23.

The Mode Dial

The following scenes can be selected with the mode Mode dial dial:

kPortrait

Use for portraits with soft, natural-looking skin tones. If the subject is far from the background or a telephoto lens is used, background details will be softened to lend the composition a sense of depth.

lLandscape

Use for vivid landscape shots in daylight. The built-in flash and AF-assist illuminator turn off; use of a tripod is recommended to prevent blur when lighting is poor.

Page 41

Image 41

Nikon D5200 18105mm Kit, D5200 1855mm Kit Bronze Creative Photography Scene Modes, kPortrait, lLandscape, The Mode Dial
