Manual Focus

Manual focus can be used when you are not using an AF-S or AF-I lens or when autofocus does not produce the desired results (0 34).

1 Set the lens focus-mode switch.

A-M

M/A-M

If the lens is equipped with an A-M or M/A-M mode

mode switch

mode switch

switch, slide the switch to M.





2 Focus.

To focus manually, adjust the lens focus ring until the image displayed on the clear matte field in the viewfinder is in focus. Photographs can be taken at any time, even when the image is not in focus.

❚❚The Electronic Rangefinder

If the lens has a maximum aperture of f/5.6 or faster, the

viewfinder focus indicator can be used to confirm whether the subject in the selected focus point is in focus (the focus point can be selected from any of the 39 focus points). After positioning the subject in the selected focus point, press the shutter-release button halfway and rotate the lens focus ring

until the in-focus indicator (I) is displayed. Note that with the subjects listed on page 34, the in-focus indicator may sometimes be displayed when the subject is not in focus; confirm focus in the viewfinder before shooting.

40

Page 56 Page 58
Page 57
Image 57
Nikon 1511, D5200, 1501 Manual Focus, Electronic Rangefinder, Set the lens focus-mode switch, Switch, slide the switch to M
Page 56 Page 58

D5200 18-55mm Kit Black, 13216, 1507, D5200 18105mm Kit, 1501 specifications

The Nikon D5200 is a versatile and user-friendly digital single-lens reflex (DSLR) camera that appeals to both photography enthusiasts and beginners. Launched in 2012, it combines advanced features with an array of easy-to-use functionalities, making it an excellent choice for capturing high-quality images and videos.

The D5200 features a 24.1-megapixel DX-format CMOS sensor, which delivers stunning detail and rich color reproduction. This high-resolution sensor is complemented by the EXPEED 3 image-processing engine that enhances overall performance by ensuring fast processing times and low noise, particularly in low-light conditions. The camera's ISO range spans from 100 to 6400, expandable to 25600, making it adaptable for various shooting scenarios.

One standout feature of the D5200 is its 39-point autofocus system, which includes 9 cross-type sensors for precise focusing even in challenging lighting situations. The Multi-Cam 4800DX autofocus module allows for quick subject tracking during action shots, ensuring that your subjects are always in focus. Additionally, the camera offers 11 different AF-area modes, granting photographers the flexibility to choose the best approach for their shooting needs.

The D5200 boasts a 3-inch vari-angle LCD monitor, providing creative framing options for both stills and video. This articulating screen allows users to shoot from unusual angles and capture unique perspectives, enhancing the overall creative experience. The camera also supports Full HD 1080p video recording at various frame rates, providing the capability to create professional-quality video content.

Nikon offers the D5200 in several kits, including the D5200 with an 18-55mm lens, which is an ideal starter option, and the 18-105mm kit for those looking for a bit more versatility. The 18-55mm lens provides a standard focal range perfect for everyday photography, while the 18-105mm lens caters to a wider range of shooting experiences, from landscapes to portraits.

The camera utilizes built-in Wi-Fi, enabling easy sharing of images and remote control capabilities through a compatible smartphone or tablet. Other significant features include a built-in flash, multiple exposure modes, and an HDR mode that helps in capturing high-contrast scenes.

In summary, the Nikon D5200 is a feature-rich DSLR that combines high resolution, advanced autofocus capabilities, and user-friendly design, making it an excellent tool for a wide range of photographic endeavors. Whether you are shooting still images or creating videos, the D5200 proves to be a reliable and adaptable companion for any photography enthusiast.
