PROJECTION TABLES

The low-budget model – No. 6293-2 The universal model - No. 6295

The good value model – No. 6533

➠ ➠

stepless height adjustment 60 -100 cm

two horizontally

and vertically

adjustable trays 45 x 30 cm each

➠ ➠

stepless height adjustment 75 -100 cm

Simple projection table for ohps, with base 38 x 39 cm. With 4 castors, 2 of them lockable. Weight: 7 kg.

Practical projection table for ohps. With four castors, 2 of them lockable. Base 45 x 45 cm

Weight: 13 kg

Projection table for ohps with two different working levels up to a height of 72 cm.

Base 50 x 50 cm. With four castors, two of them lockable. Weight: 11 kg.

Optional deposit tray No. 6531

The bestseller model – No. 6535

stepless





height



adjustment



75 -120 cm

Projection trolley for ohps of sturdy steel tube construction.

Cutout: approx. 42 x 53 cm

Dim.: 60 x 70 x 75/120 cm

Weight: 17 kg

The comfortable model – No. 6524

stepless





height



adjustment

73 -100 cm

Sturdy and elegant projection table for a lecturerworkingwithanohpinsittingorstanding position.Withfourcastors,twoofthemlockable. Cutout: 43 x 54 cm, base: 54 x 63 cm Weight: 28 kg

The allround model – No. 6526-1

stepless





height



adjustment

85 -112 cm

Projection table with tiltable working surface 40x63 cm for slide projectors, d/v projectors and opaque projectors. Extendable tray for notebook 38x44 cm. With four castors, two of them lockable.

Weight: 35 kg

The DVP model – No. 6522

Projection table for slide projectors, d/v projectors and opaque projectors. With tiltable projector tray 40x50 cm, with safety rail, working surface for displays and other accessories. With four castors, two of them lockable.

Weight: 13 kg

Optional deposit tray 40x32 cm No. 6522-1

The StandMaster model – No. 6375

Mobile projection table with adjustable deposit trays a= 42 x 35 cm, for up to 10 kg weight; b= 36 x 24 cm, for up to 5 kg weight.

Can also be used as transport trolley.

The Gigant model – No. 5661

Sturdy and safe projection table, 115 cm high, with two trays,

a= 40 x 50 cm, for up to 25 kg weight, b= 40 x 40 cm, for up to 15 kg weight.

The Solo 9000 model – No. 5665

Projection table with rimmed tray, tiltable tray 40 x 50 cm, for up to 20 kg weight.



a)

No. 6522

b)

No. 6375

Stepless height

adjustment

stepless height

79–120 cm.

adjustment



85–125 cm

a)

b)

No. 5665

stepless height adjustment 80–125 cm

No. 5661

Subject to technical alterations, as well as to changes of the design and the colour
