5- Recording CDs
1Press the MENU key repeatedly until the SRC> XXX appears.
2Turn the MULTI dial to set the value ON or OFF.
NOTE
When the SRC setting is off, the frequency conver- tor is bypassed. In this case, digital signals other than 44.1kHz cannot be recorded. If an attempt
is made, the error message Not Fs44.1k! will appear on the display.
Basic recording
WARNING
If you are monitoring using headphones, first adjust the level control to low on the unit, then connect to the PHONES jack before playing back. This will pre- vent any possible damage to your hearing.
NOTE
According to the “Red Book” (the specification for audio CDs), a track cannot be less than four sec- onds in length, and there can be a maximum of 99 tracks on an audio CD. Bear these limitations in mind when recording.
If you press either the STOP or PAUSE key within four seconds of starting recording, the unit will continue recording until four seconds have elapsed (since the start of recording) and then stop or pause as appropriate.
After selecting the input source(s) (see “Input selection” on page 20), it is possible to start recording.
The basic record procedure is as follows:
1Load a recordable disc into the unit. As the disc is loaded, the display shows TOC Reading.
When the disc has been loaded, the display indi- cators show
2Press the RECORD key. The unit enters record standby mode, as shown by the REC and pause in- dicators on the display. As the unit enters record standby mode, the display shows Now OPC (Opti- mum Power Control).
3Adjust the level of the source(s), following the guidelines in “Signal volume” on page 20.
NOTE
The red OVER indicators on the meters should never light. Unlike analog equipment, digital audio units produce unpleasant sounds when distorted, and there is no “headroom” after the 0 mark. If record- ing digitally from a
An analog signal input at nominal level, with no cut or boost from the volume controls, is equivalent to a reading of
4Press the PLAY key or the PAUSE key to start recording.
Note that there is no need to “cue up” the re- cording
5Press the PAUSE key to pause recording tempo- rarily. The pause indicator on the display ap- pears.
Pressing the PAUSE or PLAY key again restarts recording with a new track number.
6Press STOP to stop recording. When recording stops, the display shows PMA Writing (Program
Memory Area) and the REC indicator blinks for a few seconds as the unit writes to the disc.
NOTE
While the ”PMA Writing” message is displayed, all keys are disabled, and the unit is actually writing to disc. Do not disconnect the power or subject the unit to severe vibration or shocks at this time, as this will prevent proper recording of the informa- tion.
7When this message disappears, you must press the RECORD key (step 2) before restarting the recording. Recording restarts with a new track number.
NOTE
Remember that every time recording is paused or stopped, when recording is restarted, a new track will always be started. It is not possible to record in two ”stages” within one track.
TASCAM
