Installing the HSIM-W87

9.Secure the HSIM-W87 to the module faceplate using the mounting screws saved in Step 5.

10.Secure the HSIM-W87 to the module standoffs using the standoff screws included in the HSIM-W87 shipping materials.

11.Reinstall the interface module in the chassis.

12.Reattach the network cabling to the interface module.

2.2.2Installing the HSIM-W87 in a Standalone Device

To install an HSIM-W87 into a standalone device (e.g., 2H252-25R) perform the following steps:

1.Power down the device and remove the power cord.

2.Note the ports that have cables attached to them. Write down the ports and label the cables to make it easier to reattach the network properly after the installation. Then disconnect those cables from the ports.

To install the HSIM-W87 in a standalone device the device must first be powered down. Ensure that you remove the power cord and ONLY the screws required to remove the chassis cover.

3.Attach the antistatic wrist strap (refer to the instructions outlined on the antistatic wrist strap package).

4.Remove the standalone device chassis cover (refer to your specific standalone device documentation for instructions on removing the chassis cover).

5.Refer back to Figure 2-1and remove the two faceplate mounting screws and the HSIM coverplate. Save the screws.

6.Refer back to Figure 2-2and place the HSIM-W87 behind the standalone device faceplate.

7.Align the HSIM connector of the HSIM-W87 with the pins on the standalone device.

HSIM-W87 User’s Guide 2-5
