Page 10



(Only for S5201)



2. SW source DetectionPlease see Appendix E Item 9















22.0 Alarm sound











(Only for S5201B/ S5301WB)













22.1 Power on Beep sound



Frequency follows Acer SW spec 1.19. Only one volume





22.2 Timer



Frequency follows Acer SW spec 1.19. Three kinds of







volume setting



















3D Projection :











This function is only for 3D contents and must wear 3D glasses.



TI DDP DDP2430





TI DDP DDP2431

Does not support FRC (Frame Rate

Support FRC (Frame Rate



Conversion)





Conversion)

Can not support HQFS 60Hz 3D source

Can support HQFS 60Hz 3D source



from DVD which need to go thru FRC



from DVD which need to go thru FRC

Can only support 120Hz 3D source from

Can support 120Hz 3D source from



PC (VGA/DVI/HDMI)





PC

OSD :

Add “3D”, “3D Sync L/R” in Image Page

3D : NVIDIA 3D, DLP 3D, off. Default is Off. All of acer 3D models are support both NVIDIA and DLP. (V1.17 08/21 update)

“3D Sync L/R” is adjustable when above "3D" is on. Otherwise gray out. When you discover the inversion of the image depth (for your Left/Right eyes), do the invert action to solve this condition. (V1.17 08/21 update)

When choose NVIDIA 3D , 3D Sync L/R is still gray out. (V1.18 09/30 update).

3D Sync L/R only enable for DLP 3D, otherwise it will be gray out (V1.18 09/30 update).

When 3D is enabled, Display Mode and Color temperature (in Color Page) is not adjustable.

Function disable :

When 3D is enabled, eView Management and all empowering function (eTimer,

eOpening, ePower) are gray out. eKey is disable (V1.18 09/30 update) When meeting 60/120Hz (no matter 3D on or off, HSG only one set value), if enduser adjust adjustable items (ex. brightness), the value will not been stored and only for that use only.

For DDP2430 models : 3D / 3D Sync L/R (V1.17 08/21 update) , only appear for VGA/DVI/HDMI source. Disappear if other sources.

For DDP2230/2431 models : no this limitation.

10
