Key Features

Specifications

Works with any 802.11b or 802.11g access point

Supports peer-to-peer networking with one another or any 802.11b/g station devices

Supports TCP/IP and UDP networking over 802.11

Plug & Play operation—

oNo driver on the host device is required

oOperation independent of operating system on the host equipment or device (Windows 98/NT/2000/ME/XP, Linux, Unix, embedded, etc.)

Supports 64-bit and 128-bit WEP encryption for secured communication

11Mbps data rate and automatic selection of lower data rate (5.5, 2 and 1 Mbps) in degraded RF environment

Serial interface supports XON/XOFF, DTR/DSR (WiSER2400.IP and WiSER2400.Plus) and RTS/CTS (WiSER2400.Plus) for both local and remote hand-shake/flow control

Supports RS-232 interface (WiSER2400.IP)

Supports RS-232/485/422 interfaces, selectable by software configuration (WiSER2400.Plus)

Compact integrated omni-directional-antenna (WiSER2400.IP) Reverse-SMA RF connector for antenna attachment (WiSER2400.Plus)

Microsoft-Windows-based administrative software

Protocols supported: TCP, UDP, ICMP, ARP

Comes with a virtual serial COM port redirector software, VirCOM

Model

WiSER2400.IP; WiSER2400.Plus





Standard

802.11 and 802.11b





Host Interface

RS232 (WiSER2400.IP)



RS232/485/422 (WiSER2400.Plus)

Frequency

2.4GHz – 2.497GHz





RF Channels

11 channels (US, Canada), 13 channels (Europe, Japan)





Transmission

16dBm at antenna input typical

power



RF Receiver

-80dBm @1e-5 BER typical

sensitivity



Antenna

2 dBi integrated dipole antenna (WiSER2400.IP); Reverse-



SMA RF connector (WiSER2400.Plus)

Wireless Data

11, 5.5, 2 or 1 Mbps fixed rate, or configured to automatic

Rate

rate selection

Wireless

CCK, Direct Sequence Spread Spectrum

Modulation



Wireless Link

300 ~1200 ft (WiSER2400.IP, depending on environment);

Distance

Link Distance for WiSER2400.Plus depends on antenna



used

Wireless Network

Support infrastructure and ad-hoc station modes

Types



Wireless Data

Support the standard 64-bit and the 128-bit WEP

Encryption



Network Security

MAC-address-based access control





Serial Port

Data Bit: 7/8; Parity: none/even/odd; Stop Bit: 1

Interface



Serial Data Rate

1200, 2400, 4800, 9600, 14.4K, 19.2K, 38.4K, 57.6K,



115.2K

Input Power

5VDC for WiSER2400.IP (adapter provided); 5VDC to 32



VDC for WiSER2400.Plus (to be supplied by user)

Current

<480mA (max. reached in transmit-mode)

consumption



LED Indicators

4: Power, Transmission, Receiving, Link





Operating

-10°C – 50°C

Temperature



Regulation

FCC part 15,Class B

Compliance

CE (ETSI EN 300 328-1, ETSI EN 301 489-17)



IC

WiSER 2400 Technical Manual

Version 2.16

Copyright  2001-2005, OTC Wireless, Inc. All Rights Reserved

Page 5 of 32
