3Com 2426-PWR, 2226-SFP, 2250-SFP manual User Summary, Create User

Page 41

To ensure that unauthorized users do not access the Web interface, 3Com recommends that you set an admin password when you first configure the Switch.

Even if you do not intend to actively manage the Switch, 3Com recommends that you change the password to prevent unauthorized access to your network.

The password can be up to 8 characters long and is case-sensitive.

If you forget the administration password after you set it, refer to “Resetting to Factory Defaults” on page 75 for information on how to regain access to the Web interface.

User Summary

Displays the list of user names and their access level.

Figure 22 User Summary Screen

Administration Settings

41

Create User

This page allows you to create a user and define the access level and password for that user.

Figure 23 Create User Screen

Image 41
