Chapter 2 Motion M1200 and M1300 Tablet PC Hardware









Table 2-1 Tablet PC LEDs, Buttons, Connectors, and Other Components





Pen holder

Storage for the Motion M-Series Digitizer Pen





Power LED

Displays power status





Battery LED

Displays battery status





Hard Disk Drive LED

Displays Hard Disk Drive activity





Wireless LED

Displays wireless status (ON or OFF) and activity





Escape Button

Primary function (not programmable): Esc. Secondary function (programmable): Alt+Tab





Function Button

Press this Function button + another button to activate Secondary functions





Five-way Directional

Primary functions (not programmable): Scrolls Up/Down/Right/Left + Enter

Control Button

Secondary functions (programmable): Left arrow—Shift+Tab; Right arrow—Tab; Up



arrow—Page Up; Down arrow—Page Down

Hot Key #1 Button

Primary function (programmable): Displays Dashboard



Secondary function (programmable): Opens the Windows Journal.





Hot Key #2 Button

Primary function (programmable): Changes the Tablet PC display orientation.



Secondary function (programmable): Opens the Tablet PC Input Panel.





Security Button

Primary function: Ctrl-Alt-Del; Secondary function: None





Built-in, mono microphone

Works at a natural distance; disabled when an external microphone is plugged in





Pen tether

Attach a pen tether to this post to secure the Pen.





PC Card slot

Holds one Type-II PC card for networking, memory expansion or accessory connections.



A plastic blank ships in this slot in the Tablet PC; leave this installed when not in use.

Antenna cover

802.11 wireless networking antenna cover; this area does not open





Power switch

Turns the Tablet PC on and off; can configure to activate Hibernate or Stand By modes





AC power jack

Connects to the Motion M-Series AC Adapter through a right-angled connector on the



Adapter. Use only a Motion M-Series AC Adapter for either Tablet PC.





Speakers (2) integrated

Speakers mute when a headset or external speakers are connected.





RJ-11 Modem port

Connector for a 56.6K V.90 modem





RJ-45/LAN

Standard RJ-45 connector for a 10/100 Mbps network





RJ-45 LEDs (2)

Display status of the LAN connection; blink green/amber for a connection





External monitor

Fits a standard DB-15 monitor connector for an external monitor.





Docking connector

Docks with the Motion M-Series FlexDock





USB ports (2)

Each Universal Serial Bus port connects USB accessories, such as a



, mouse, printer, or digital camera.





IEEE 1394 port

Connects 4-pin accessories, such as DVD players, optical disk drives, video cameras and



other electronics.

Audio-in/Microphone

Input jack for 3.5mm plug for a microphone





Audio-out/Headphone

Input jack for a 3.5mm plug for a headset; mutes the built-in speakers





Battery

Self-monitoring battery monitors the amount of charge and notifies the Tablet PC of how



long it will operate with the current power consumption; user swappable





Battery release latch

Slide this latch to remove the battery.





Battery gauge

Push the button next to the LEDs to check the battery’s charge.





Memory/mini-PCI access

256MB RAM (standard) upgradeable to 1GB. For information about upgrading memory,



see Chapter 4 of this User Guide.





Security lock slot

Fits a Kensington-style cable lock for securing the unit to a desk, etc.





Hard drive bay

20GB (standard); optional 40GB and 60GB hard drive capacity





Product Identification

Serial numbers, System certifications





Motion Computing M1200 and M1300 Tablet PC User Guide 13
