Wacom DTI-520 manual Basic Operations of the Pen, Moving the Pointer, Clicking and Double-clicking

Page 20

Basic Operations of the Pen

Moving the Pointer

By raising the pen a little above the screen and moving it, you can move the position of the screen pointer.

Clicking and Double-clicking

Clicking

Tap on the screen lightly once with the tip of the pen to click.

Double-clicking

Tap in the same place twice quickly with the tip of the pen to double-click.

Note

The second side switch is set to double-click as a default setting.

Dragging

Select an icon or folder and then, while keeping the pen tip pushed down, move the pen to move the object.

Using the Eraser

By setting the eraser function and then tracing over the display, pictures and handwritten characters disappear as if erased by a standard eraser.

User's Guide

19

UM-0314(A)_EN.indd 19

2007/11/12 16:53:18
