Toshiba B-443 owner manual Printer Parts, Top front view

Page 11

EO1-33013

2.4 Printer Parts

4

3

2

5

1

6

Figure 1. Top front view

1.Cover Release Button

2.PWR., ON-LINE and ERR. Indicators

3.PAUSE Button

4.FEED Button

5.Label Dispense Opening

6.Backing Paper Opening (for use with self-peeling function)
