5.3Supplies

5.3.1Label Stock

B-443 is capable of both direct thermal and thermal transfer printing. Many different direct thermal or thermal transfer stocks can be used. Refer to the following list for specifications of compatible label media.

Media

Label

Tag

Specification





Paper Width

Min. 1” (25.4 mm)

Min. 1” (25.4 mm)

Max. 4.49” (114 mm)

Max. 4.49” (114 mm)



Paper Weight

Less than 240 g/m2







Length (Pitch)

0.4” (10 mm) ~ 90” (2286 mm)

0.4” (10 mm) ~ 90” (2286 mm)







Thickness

0.002” (0.05 mm) ~ 0.008” (0.20 mm)





Max. Roll Diameter.

Inner roll diameter. Max. 4.3” (110 mm)





(1” core)

External roll diameter. Max. 8.4” (214 mm)







Roll Up Method

Print surface is wound outside as standard





Paper Core ID.

φ25.7 ± 0.3 mm







5.3.2 Ribbon

Standard 300m by 60 or 110mm thermal transfer ribbons with wax, wax-resin, or resin coating (wound outside) are available from TOSHIBA TEC CORPORATION. Of ribbon selection, it is recommended that the ribbon be at least as wide as the print media. Also, the ribbon end should be transparent.
