34 Real-Time Counter Memory

Follow the steps below to reset the real-time counter to zero at a tape location you want to refer to later.

1 Play, fast forward, or rewind a tape to the location that you would like to refer to later. Press the STOP/p button to stop the tape.

2 Press the STATUS/EXIT button to see the status display.

STOP	1:08PM
TV STEREO	CH10

MVR630MG only

SLP 1 : 23 : 45 HIFI

3 While the status display is on the screen, press the CLEAR button to reset the real-time counter to zero.

STOP	1:08 PM
TV STEREO	CH10

MVR630MG only

SLP 0 : 00 : 00 HIFI

4 While the real-time counter is on the screen, press the MEMORY button so that M appears beside the counter.

STOP		1:08 PM
TV STEREO		CH10
					MVR630MG only
SLP M 0 : 00 : 00		HIFI

5 To go to a tape location where the real-time counter was reset to zero, press the REW(ind)/{ button or the F.FWD/B button when playback is stopped. When the tape reaches the point at which the counter was set to zero, the tape will stop.

Press the PLAY/o button to watch the tape.

	5		EJECT
	5
	PLAY
REW			F.FWD
1	STOP		3
1	2STATUS/EXIT	3	3
4	2		CH
4
7
	0
SPEED	TIME SEARCH STILL/PAUSE

4 MEMORY SLOW

Helpful Hints

•The MEMORY button does not function if REPEAT PLAY is ON. Details are on page 33.

•To erase a real-time counter memo- ry, press the MEMORY button until the M disappears from the screen.

•You may only set the real-time counter to zero at one location at a time. Setting the real-time counter to zero at a second location will erase the previous real-time counter to zero setting.
