Toshiba SD-37VBSB Remote control, How to install the batteries, Front If the batteries have not

Page 11

Remote control

How to install the batteries

Use micro batteries type UM-4 (R03/AAA-Size).

These batteries are offered as carbon / zinc-type or as alkaline-type. You may use both, but do not mix types. The alkaline type lasts longer compared to the carbon / zinc type but is more expensive.

Note: Flat, weak batteries will leak. Corrosive electrolyte will damage the remote control handset.

Leak proof batteries will not leak immediately when they are flat. As long as the handset is still working, there is no danger of leakage. To prevent damage, remove the batteries if you do not use the handset for several months.

Damage because of leakage is not covered by the guarantee.

1 Open the battery compart-

2 Install two "R03/AAA" batteries

3 Replace the compartment

ment cover in the direction of

(supplied), paying attention to the

cover.

the arrow.

polarity diagram in the battery





compartment.



Distance of Remote

Control Operation

approx.

7m

Effective angle: approx. 60°

Point the remote control directly at the remote sensor.

The remote control handset will not work properly in the following cases:

If bright sunlight

If an obstacle is

directly beams

placed between the

onto the unit

unit and the handset.

front.



If the batteries have not

If the batteries are

been installed according to

weak.

their polarities.



11

2J50101A [EN] P08-13

11

27/2/06, 5:38 PM
