Toshiba SD-37VBSB manual Recording a TV Program, To Stop Recording Temporarily, Press Stop

Page 25

Recording a TV Program

Notes:

Since the DVD/VCR has a built-in TV tuner the TV set may be turned off when recording. The TV set may only be used to check for accurate program adjust- ments or to monitor recordings.

If you wish to watch the DVD playback during the recording on VCR, press DVD to change to DVD mode and per- form the DVD playback (see page 33).

Preparation

Turn ON the TV and set to the AV input mode.

Press VCR to select the VCR mode. (The VCR indicator will light.)

1 Load a blank cassette tape with the erase prevention tab intact. (The DVD/VCR will auto- matically turn on.)

VCR

2 Select the program(e.g.29) you want to record with CH +/– or Number buttons (0-9).

1~9 : e.g. 5 = press “5

VCR

10~80 : e.g. 29 = press “2” and “9”.

3 If a recording in Long Play mode is intended, press SP/LP to display “LP”.



REC

￿￿￿￿￿

4 Press REC/OTR to start recording.

￿￿￿￿￿￿￿￿￿￿￿￿￿￿



VCR













If the erase prevention tab is removed, the tape will eject when REC/ OTR is pressed for recording. (see p.19)

To Stop Recording

Press STOP.

VCR

To Stop Recording Temporarily

To stop a recording for a short period of time press PAUSE/STEP. Press this button again if you want to resume the recording.

VCR

REC

Attention:

A safety circuit turns the pause mode off automatically after 5 minutes, and the DVD/VCR will stop the recording mode.

25

2J50101A [EN] P25-32

25

27/2/06, 5:39 PM
