Before requesting service (troubleshooting), please check the following.

Power Requirements

AC 120 V, 60 Hz

Power Consumption

15 W

Problem

No operations can be performed with remote.

Disc does not play.

5.1channel sound is not being reproduced.

The

icon appears on

screen.



Disc Menu doesn’t appear.

Play mode differs from the Setup Menu selection.

The screen ratio cannot be changed.

No audio.

Forgot password

If you experience other problems.

Action

Check the batteries in the remote. May need replacing.

Operate the remote control at a distance of no more than 20 feet.

Remove batteries and hold down one or more buttons for several minutes to drain the microprocessor inside the remote to reset it. Reinstall batteries and try remote again.

Ensure that the disc is installed with the label side facing up.

Check the region number of the DVD.

5.1 channel sound is reproduced only when the following conditions are met. :

1)The DVD player is connected with the proper amplifier

2)The disc is recorded with 5.1 channel sound.

Check whether the disc being played has the “Dolby 5.1 ch” mark on the outside.

Check if your audio system is connected and working properly.

In a SETUP Menu, is the Audio Output set to Bitstream?

The features or action cannot be completed at this time because:

1.The DVD’s software restricts it.

2.The DVD’s software doesn’t support the feature (e.g., angles).

3.The feature is not available at the moment.

4.You’ve requested a title or chapter number or search time that is out of range.

Check if the disc has a Menu.

Some of the functions selected in the Setup Menu may not work properly if the disc is not encoded with the corresponding function.

The Screen Ratio is fixed on your DVDs.

Make sure you have selected the correct Digital Output in the Audio Options Menu.

Press power on from a cold start with no disc in the unit. Press the STOP and PLAY buttons simultaneously on the front panel for three seconds. The Select Menu Language display will appear. Select the desired language button. Press the SETUP button on the remote control to select the Parental Mode. The Parental Mode is now unlocked as indicated on the display. Press the DOWN button to select Parental. Press ENTER and the Create Password display will appear. You can now set your rating level and change your password to a new number.

Go to the contents and find the section of the instruction book that contains the explanations regarding the current problem, and follow the procedure once again.

If the problem still cannot be solved, please contact your nearest authorized service center.

Page

P6

P9

P14

P17

P35~40

P40

P39

P38

General

Weight

15.4 lbs

Dimensions

W 16.9 in x D 15.9 in x H 3.5 in





Operating Temperature Range

+41°F to +95°F



Operating Humidity Range

10 % to 75 %



DVD

Reading Speed : 11.45 ft/sec.



(DIGITAL VERSATILE DISC)

Approx. Play Time





(Single Sided, Single Layer Disc) : 135 min.

Disc

CD : 5"

Reading Speed : 3.9 to 4.6 ft/sec.

(COMPACT DISC)

Maximum Play Time : 74 min.





CD : 31/2"

Reading Speed : 3.9 to 4.6 ft/sec.



(COMPACT DISC)

Maximum Play Time : 20 min.



VCD : 5"

Reading Speed : 3.9 to 4.6 ft/sec.





Maximum Play Time : 74 min. (Video + Audio)



Composite Video

1 channel : 1.0 Vp-p (75 Ω load)



Component Video

Y : 1.0 Vp-p (75 Ω load)

Video



Pr : 0.70 Vp-p (75 Ω load)



Pb : 0.70 Vp-p (75 Ω load)

Output



S-VIDEO

Luminance Signal : 1.0 Vp-p (75 Ω load)







Chrominance Signal : 0.286 Vp-p (75 Ω load)



2 Channel

L(1/L), R(2/R)



*Frequency Response

48 kHz Sampling : 4 Hz to 22 kHz

Audio



96 kHz Sampling : 4 Hz to 44 kHz

*S/N Ratio

110 dB

Output

*Dynamic Range

100 dB





*Total Harmonic Distortion

0.004 %





*: Nominal specification

Samsung Electronics Co., Ltd. reserves the right to change the specifications without notice.

Weight and dimensions are approximate.
