Panasonic DMP-BD70V Remote control and unit reference guide, Power button Power Í/I

Page 14

Remote control and unit reference guide

! Turn the unit on and off (> 15) @ TV operation buttons (> 15)

You can operate the TV through the unit’s remote control.

[Í TV POWER] : Turn the television on and off

[INPUT] : Input select

[i j VOL] : Adjust the volume

[W X CH] : Channel select

# Open or close the disc tray (> 19)

$ Select title numbers, etc./Enter numbers or characters (> 18, 20)

(The character buttons may be used when operating VIERA CAST contents. B 27) [CANCEL] : Cancel/Reset the tape counter (> 17, 26)

% Basic playback control buttons (> 20, 21, 26) ^ Show status messages (> 21, 26)

& Show Pop-up menu (> 20)

* Show Top menu/Direct Navigator (> 20) ( Show sub menu (> 24)

AJ These buttons are used when:

≥Operating a BD-Video disc that includes JavaTM applications (BD-J). For more information about operating this kind of disc, please read the instructions that came with the disc.

≥Displaying “Title View” and “Album View” screens. (Only the [R] and [G] buttons, B 24)

≥Operating contents of VIERA CAST. (> 27) AA Show Setup menu (> 32)

AB Switch on/off Secondary Video (Picture-in-picture) (> 23)

AC Transmit the remote control signal AD TRACKING/V-LOCK (> 26)

AE Select audio (> 21, 26)

AF Reproduce more natural audio (> 21) AG Show FUNCTIONS menu (> 21)

AH Selection/OK, Frame-by-frame (> 21) AI Show on-screen menu (> 30)

BJ Return to previous screen

BA Select drive (BD/DVD/CD, SD card, USB device, VHS) (> 20)







BB Displays the Home screen of the VIERA CAST









(> 27)





EJECT





OPEN/CLOSE















POWER









SD CARD













Pull to flip down the



front panel.

1Cassette eject button (> 19)

2 Cassette compartment (> 19)

3 Open or close the disc tray (> 19)

4 Disc tray (> 19)

5 SD Card LED

≥It is possible to set the LED to turn on/off. (> 33, SD Card LED

Control)

6POWER button (POWER Í/I) (> 15)

Press to switch the unit from on to standby mode or vice versa. In standby mode, the unit is still consuming a small amount of power.

7Remote control signal sensor (> 5)

14

8Display

Disc indicator SD card

Tape indicator USB access

indicator

lamp

The indicator and access lamp blink when reading data from a card, or USB device, or writing data to a card.

9Stop (> 20, 26) : Pause (> 20, 26)

;Start play (> 20)

<USB port (> 19)

=SD card slot (> 19)

Rear panel terminals (> 10–13, 16)

RQT9412
