MENU

6.3 TIMER SETTING MENU

TIMER SETTING MENU



WEEK

START

STOP

SPEED SET

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

SUN

00:00

23:59

50 IPS

OFF

In TIMER SETTING MENU we define automatic, timer-controlled records.

Timer records can be defined for 16 individual start and end times.

(1)WEEK: Select the week day for the timer to record on schedule. DLY means daily record.

(2)START: Enter the start time for timer recording.

(3)STOP: Enter the end time for timer recording.

NOTE:

The recorder records until the end of the minute which is set here.

EXAMPLE: START 07:00

END 08:00





The recorder records from 07:00:00 until 08:00:59



Each day has to be set separately:



EXAMPLE: Daily record from 20:00 till next day 07:00



WRONG:

DLY

START 20:00

STOP 07:00



CORRECT:

DLY

START 20:00

STOP 23:59





DLY

START 00:00

STOP 06:59

(4)SPEED : Select recording speed. Maximum 60 (NTSC) / 50 (PAL).

(5)SET: Select “ON” when using timer recording.

Select “OFF” when not using timer recording.

Turn the JOG dial clockwise or counter-clockwise to select the options.

Press ENTER key to confirm the option and move to next column.

ENTER

Press MENU key to return to Main Menu, press again to leave Set up Menu.

MENU

13
