EverFocus EDSR-900, EDSR-1600 instruction manual Instant Recording, Alarm Recording

Page 38

Recording

7.1 INSTANT RECORDING

Press REC key to start continuous recording with setting of “NORMAL RECORD”.

The recording rate and recording quality are set in the RECORD SETTING MENU.

REC

The LCD screen on the front panel of DVR will display as follows:

2003/11/23

21:56:47

REC HDD1 70%

50 IPS 21:56:52

Display shows operation status, active HDD, record position on active HDD, record frame rate ant current time.

REC, Maximum 60 (NTSC) / 50 (PAL) fields will also show on the main monitor display if you press the DISPLAY key to show camera title and date/time.



Press STOP key to stop recording.

STOP

Since the DVR had Duplex feature, STOP key can be activated both in Playing back and

Recording. In Duplex mode first STOP will stop playback, second STOP will stop recording.



When the HDD is full, the machine will Stop recording automatically or Auto Overwrite from the beginning of the HDD. It depends on the setting in RECORD SETTING MENU.

7.2 ALARM RECORDING

When the ALARM OPERATION setting is “ON”, the DVR will automatically record

when alarm occurs , and will automatically stops recording at the end of the alarm duration period.

As example, we set ALARM RECORDING SPEED on 60 (NTSC) / 50 (PAL) field, the screen will show as below,

A.REC (50IPS)

DISK: 39 GB

Instant recording and timer recording will stop when an alarm occurs.

Please refer details in RECORD SETTING MENU (page 20).

33
