Mace DVR1604RW, DVR0404RW, DVR0804RW manual Menu Overview, Menu level Remarks

￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿￿

Menu	Overview
Main menu		Menu level 1					Menu level 2		Remarks
		RECORD	CH	1					Use DIRECTION arrows to perform settings
			DATE	24-10-2003
									in menu level 2
			TIME	2:20 PM
									See details
			PLAY	START
SEARCH
		LIST	CH	1					Use DIRECTION arrows to perform setting
			DATE 24-10-2003
									in menu level 2.
			TIME	2:20 PM
									See details
			LIST	SEARCH
		ALARM	CH	1					Records associated with Alarm Inputs. Not
			DATE		24-10-2003				able to search motion detection records.
			SEARCH		START				See details
			HDD NUM 0 2
		FILE INFO	HDD CAP 0 1 6 0 0 8 6M
			FREE SPACE 0 0 0 0 0 0 0 M
			FILE START 2003-04-12					01￿30AM
			FILE END		2003-05-13			09:00PM
		HARD DISK	INDEX			￿￿￿￿￿￿￿￿
			MASTER
		STATE
			SLAVE
INFORMATION
			USB STATE NO						Information cannot be modified
		VERSION	BIOS VERSION 2.45
			ISSUE DATE 03 01 2003
			WEB VERSION 1.23

BPS

CH.1	CH.2	CH.3	CH.4
0538Kb	0302 Kb	0267 Kb	0112 Kb
256M/H 132M/H		117 M/H	49M/H
CH.5	CH.6	CH.7	CH.8
0663 Kb	0227 Kb	0050 Kb 0283 Kb
291M/H	99M/H	21M/H	124M/H
