Instruction: Camera Operation
Auto Gain Control
1.After the Setup menu is displayed, press the Up/Down buttons to move the arrow to “AGC.”
2.Press the Left/Right buttons to select a mode. As the Gain level increases, the screen becomes brighter and noise level increases.
High : Gain automatically changes from 0 up to the maximum of 60dB.
Low : Gain automatically changes from 0 up to the maximum of 54dB.
Off : Off
SETUP |
|
CAMERA ID | OFF |
BACKLIGHT | OFF |
WHITE BAL. | ATW |
MOTION DET. | OFF |
LENS | DC |
SHUTTER | MANUAL |
AGC | HIGH |
OFF | |
SSNR | MIDDLE |
SPECIAL |
|
EXIT |
|
Sens-Up
Automatically detects the level of darkness (e.g. at night or under low illumination) and makes adjustments to keep the screen bright and clear.
1.After the Setup menu is displayed, press the Up/Down buttons to move the arrow to
2.Press the Left/Right buttons to select a mode.
Auto : Automatic
Off : Off
COLOR CCD CAMERA 30 User’s Manual
SETUP |
|
CAMERA ID | OFF |
BACKLIGHT | OFF |
WHITE BAL. | ATW |
MOTION DET. | OFF |
LENS | DC |
SHUTTER | MANUAL |
AGC | HIGH |
OFF | |
SSNR | MIDDLE |
SPECIAL |
|
EXIT |
|
3.Press the Set button when done.
Caution
•Press the Setup button from the Auto menu to adjust the
•As the rate increases, the screen gets brighter but the ghost image gets larger as well.
•Shutter is not available when Auto mode is selected.
COLOR CCD CAMERA 31 User’s Manual
