Display Problems

There are several main conditions or sources of possible interference that may cause problems with the quality of the information displayed on the control head. Look in the following table for some symptoms of display problems and possible solutions:

Problem

Possible Cause

The control head loses power at If the power output of your boat’s engine is unregulated,

high speeds.the control head may be protecting itself using its over- voltage protection feature. Make sure the input voltage does not exceed 20 Volts.

Finding the Cause of Noise

Electrical noise usually affects the display with many black dots at high speeds, and high sensitivity readings. One or more of the following sources can cause noise or interference:

Possible Source of Noise

Isolation

Other electronic devices

Turn off any nearby electronic devices to see if the



problem goes away, then turn them on one at a time to



see if the noise re-appears.

The boat’s engine

To determine whether the boat’s engine is the source of



the noise, increase the RPMs while the boat is in neutral



and stationary to see if the noise increases

When the boat moves at higher speeds, the bottom disappears or suddenly weakens, or the display contains gaps.

There are no fish detected, even when you know they are in the water under the boat, or sonar readings seem weak or faulty.

The transducer position may need to be adjusted. A mix of air and water flowing around the transducer (cavitation) may be interfering with the interpretation of sonar data. See your Installation Guide for suggestions on adjusting the transducer position.

Electrical noise from the boat’s engine may be interfering with sonar reception. See Finding the Cause of Noise for more information.

Sonar readings may be affected if the transducer is not positioned correctly (i.e. mounted at an angle, not straight down), or there is some kind of mechanical interference, either because it is mounted inside a hull that is too thick for proper sonar transmission, the bond between the transducer and the hull is not airtight, or because the transducer is dirty. Check with your Installation Guide for guidance on re-positioning the transducer, and make sure the transducer is clean.

Low battery voltage may be affecting the power of signal transmission.

Electrical noise from the boats engine may be interfering with sonar reception. See Finding the Cause of Noise for more information.



proportionately; if noise appears when you rev the



engine, the problem could be the spark plugs, alternator,



or tachometer wiring. Replace the spark plugs with



resistor plugs, install an alternator filter, or route the



control head power and transducer cables away from the



engine wiring.

Cavitation from the boat’s

Turbulence created by the propeller can cause noise;

propeller

make sure the transducer is mounted at least 15” (38 cm)



from the propeller, and that the water flows smoothly



over the face of the transducer at all times.
