Panasonic WV-CP314, WV-CP310, WV-CP304, WV-CP300 VMD setting VMD, Set motion detection

Page 17

Note:

Images may not be displayed appropriately without burst signals when camera images are displayed in the black-and-white mode depending on a monitor or VCR model to be used. In such a case, set the burst signal output to "ON".

9 VMD setting [VMD]

The VMD function allows the camera to detect object motion and hindrance to the camera. Detection of object motion or hindrance to the camera can be announced by issuing an alarm signal.

Important:

The following circumstances may result in detection failure or false detection. Use the cam- era after adjusting the detection area and sensitivity.

Not enough difference in brightness between the background and the moving photo- graphic subject, or significant changes in brightness.

Dirt or water drops on the lens.

Insufficient brightness when shooting at night.

The subject is moving straight at the camera.

The subject is moving too fast or too slow.

The subject is too small or too large.

There are too many moving objects.

Light reflected through a window or from a road surface.

The camera is shaking.

Entry of outside light, such as sunlight or the headlights of a car.

Flickering fluorescent light.

Subject change detection may fail in the following cases.

The lens is partially covered or covered with a transparent item.

The photographic subjects before and after changing the camera direction are similar.

False detection may occur for approx. 1 minute after turning on the power, after completing settings in the SETUP menu, or after changing the camera view angle.

Motion detection is the detection function within the screen range for electronic zoom of 1x.

“CAMERA SETUP” screen

“MOTION DET” screen

**CAMERA

SETUP**

**MOTION DET**(1)





SCENE1































....I..

20

ALC/ELC

ALC









LEVEL





SHUTTER

OFF



-

+



AGC

ON(HIGH)

DWELL TIME

2S





SENS UP

OFF

DISPLAY MODE







WHITE BAL

ATW1





ALARM

OFF











DNR

HIGH









D&N(IR)

AUTO







MASK SET



























VMD

MOTION DET











RET TOP END

RET TOP END



Set motion detection

Move the cursor to “VMD”, press the [LEFT] and [RIGHT] buttons to select “MOTION DET”.

Step 1

Move the cursor to “MOTION DET” and press the [SET] button, the “MOTION DET” menu appears.

17
