Omega DP119-RTD AC Voltage Install Remove, 1shows the location of solder jumpers W1 through W3

Page 13

Voltage Jumper Pin Settings



AC VOLTAGE

INSTALL

REMOVE





115VAC

W1, W3

W2





230VAC

W2

W1, W3



Figure 3-1shows the location of solder jumpers W1 through W3.

4

3

2

P3

1

3

P2 2

1

3

P1 2

1

S2

S4



































































(COMPONENT SIDE)

S3

S5

TRANSFORMER

W1 W2 W3

ZERO

SPAN

DISPLAY

Figure 3-1. Power Jumper Locations

6
