Kenwood TH-F7E, TH-F6A instruction manual Normal Scan, Band Scan, Scan Type Purpose, Vfo

Page 27

SCAN

Scan is a useful function for hands-off monitoring of your favorite frequencies. By becoming comfortable with all types of Scan, you will increase your operating efficiency.

This transceiver provides the following types of scans.

Scan Type

Purpose













Band Scan

Scans the entire band of the





frequency you selected







Scans the specified

Normal



Program

frequency ranges stored in

Scan



Scan

Memory channels L0/U0 ~







L9/U9





MHz Scan

Scans the frequencies within





a 1 MHz range







Scans all Memory channels





All-Channel

from 0 to 399, based on your





Scan

Menu No. 3 (MR METHOD)

Memory





settings

Scan





Scans the specified Memory





Group Scan

channel groups, based on





your Menu No. 2 (M.GPR







LINK) settings





VFO

Scans the Call channel and

Call



the current VFO frequency





Scan



Memory

Scans the Call channel and





Channel

the selected Memory channel







Checks the activities on the

Priority Scan

specified priority channels







(Pr1/ Pr2) every 3 seconds

Information Channel

Scans the Information



Scan

channels







Scans ± 5 frequencies in the







programmed step size near





VFO

the current operating





frequency. The signal







Visual





strength of each frequency is

Scan*





displayed in a bar-graph







Scans the Memory channels





Memory

and displays the signal





Channel

strength of each channel in a







bar-graph

*Visual Scan graphically shows the busy status of frequencies in a specific range.

Note:

When the CTCSS or DCS function is activated, the transceiver stops at a busy frequency and decodes the CTCSS tone or DCS code. If the tone or code matches, the transceiver unmutes. Otherwise, it resumes scanning.

Press and hold [MONI] to pause the Scan in order to monitor the scanning frequency. Release [MONI] to resume scanning.

Pressing and holding [PTT] causes Scan, excluding the Priority scan and Visual scan, to stop.

Pressing [MNU] causes Scan to stop except the Visual Scan.

Starting Scan switches OFF the Automatic Simplex Check (ASC) {page 14}.

If you press any key other than the following keys during the scan, the transceiver exits the Scan (excluding the Priority scan and Visual scan). The Priority scan stops while “Pr1” or “Pr2” is blinking: [F], [F] (1 s), [LAMP], [MONI], [SQL], [BAL], [A/B], Tuning control, [ ]/ [ ], [F] then [SQL], and [F] then [LOW].

NORMAL SCAN

When you are operating the transceiver in VFO mode, 3 types of scanning are available: Band Scan, Program Scan, and MHz Scan.

BAND SCAN

The transceiver scans the entire band of the frequency you selected. For example, if you are operating and receiving at 144.525 MHz on the A-band, it scans all the frequencies available for the 2 m band. (Refer to receiver VFO frequency range in the specifications {page 54}.) When the current VFO receive frequency is outside of the Program Scan frequency range {page 23}, the transceiver scans the entire frequency range available for the current VFO.

1Press [VFO].

2Press [BAND] to select your desired band.

3Turn the Tuning control or press []/ [] to select the frequency outside of the Program Scan frequency range {page 23}.

4Press [VFO] (1 s) to start the Band Scan.

5To stop the Band Scan, press [VFO] or [PTT].

Note:

While scanning, you can change the scan frequency direction by turning the Tuning control or press [ ]/ [ ].

The transceiver scans the frequency range that is stored in Menu No. 4 (PROG VFO) {page 39} on the A-band.

If you select a frequency within the L0/U0 ~ L9/U9 range in step 3, the Program Scan {page 23} starts.

If you press [MONI], Band Scan temporarily pauses. Release [MONI] to resume scanning.

The transceiver stops scanning in all modes when it detects a signal.

If the Fine Tuning function is ON, scanning does not stop at the busy channels.

22
