Kenwood TH-F6A, TH-F7E Scan Program Scan, Storing Program Scan Frequency Range, Press VFO

Page 28

7 SCAN

PROGRAM SCAN

You can limit the scanning frequency range. There are 10 memory channel pairs (L0/U0 ~ L9/U9) available for specifying the start and end frequencies. It monitors the range between the start and end frequencies that you have stored in memory channels L0/U0 to L9/U9. Before performing the Program Scan, store the Program Scan frequency range to one of the memory channel pairs L0/U0 ~ L9/U9.

Storing Program Scan Frequency Range

1 Press [VFO].

2 Press [BAND] to select your desired band.

3 Turn the Tuning control or press []/ [] to select your desired start frequency.

4 Press [F], then turn the Tuning control or press

[]/ [] to select a memory channel from L0 ~ L9.

5Press [MR] ([] or [MNU]) to store the start frequency in the memory channel.

6Turn the Tuning control or press []/ [] to select your desired end frequency.

7Press [F], then Turn the Tuning control or

press []/ [] to select the corresponding channel from U0 ~ U9 (you must select the same numeric value as in step 4).

For example, if you selected L0 in step 4, you must select U0 in this step.

8Press [MR] ([] or [MNU]) to store the end frequency in the memory channel.

Performing the Program Scan

1Press [VFO].

2Turn the Tuning control or press []/ [] to select a frequency within the frequency range of memory channel L0/U0 ~ L9/U9.

3Press [VFO] (1 s) to start the Program Scan.

4To stop the Program Scan, press [VFO] or [PTT].

Note:

If you press [MONI], Program Scan temporarily pauses. Release [MONI] to resume scanning.

If the Fine Tuning function is ON, the scanning does not stop at the busy channels.

The transceiver stops scanning in all modes when it detects a signal.

If more than 2 Program Scan channel pairs are stored and overlaps the frequency range among the pairs, the smaller Program Scan memory channel number has the priority.

To perform the Program Scan, the following conditions must be met. Otherwise, the Band scan starts {page 22}.

The upper and lower limit frequencies are in the same frequency band.

Ln < Un (where “n” is the Program Scan channel number).

MHz SCAN

MHz Scan allows you to scan an entire 1 MHz frequency range within the current VFO frequency.

1Press [VFO].

2Turn the Tuning control or press []/ [] to select a frequency in which to perform the MHz Scan. If you want to scan the entire 145 MHz frequency, select any frequency between 145.000 and 149.995 MHz (for example, select 145.650 MHz). Scan will operate between 145.000 MHz and 145.999 MHz.

3Press [MHz] (1 s) to start the MHz Scan.

4To stop the MHz Scan, press [MHz] or [PTT].

Note:

If the Fine Tuning function is ON, you cannot perform the MHz Scan.

If you press [MONI], MHz Scan temporarily pauses. Release [MONI] to resume scanning.

23
