Graco Inc 218-745, 307-712 Technical Data, Service Information, HOW to Order Replacement Parts

Page 29

TECHNICAL DATA

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.87 Kg (1.90 lb) Gun Length . . . . . . . . . . . . . . . . . . . . . 310 mm (12.25 in.) Maximum Working Pressure . . . . . . . . . . 7 bar (100 psi) Air Pressure Operating Range . . . 0±7 bar (0±100 psi) Fluid Pressure Operating Range . 0±7 bar (0±100 psi) Voltage Operating Range . . . . . . . . . . . . . . . . . . 0±75 KV Paint Resistivity Range . . . . 7 megohm cms to infinity Air Inlet

Turbine . . . . . . . . . . . . . . . . . . . . . . 1/4 npsm(m) L.H. Atomizing & Cylinder . . . . . . . . . . . . . . . . 1/4 npt(m)

Fluid Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8 npsm(m) Wetted Parts . . . . . . Stainless Steel, Polyethylene,

Nylon, Acetal, Vitonr￿, Delrinr

Vitonrrand Delrinr are registered trademarks of the DuPont Co.

HOW TO ORDER REPLACEMENT PARTS

1.To be sure you receive the correct replacement parts, kits or accessories, always give all of the information requested in the chart below.

2.Check the parts list to identify the correct part number; do not use the ref. no. when ordering.

3.Order all parts from nearest Graco distributor.

6 digit





Part





Number

Qty

Part Description

SERVICE INFORMATION

Listed below by assembly changed are OLD and NEW parts.

Assembly



Ref





Changed

Status

No. Part No.

Name











218±745

OLD

4

100±664

Screw

Spray Gun NEW

4

110±916

Screw











￿￿￿￿￿￿￿ ￿9
