Using Your CD±ROM Drive



Table 2±1. CD±ROM Drive Operating Controls and Features









Control/Feature



Purpose









Eject Button



Press the Eject Button to eject the disc tray. When the drive is in





use, you must unmount the disc before ejecting it. Refer to the





subsection ªUnmounting a CD±ROM discº for instructions on





umounting a disc.

Busy Indicator



The Busy Indicator lights during a data access operation and





blinks during a data transfer. The indicator stays out when there is





one of the following:





Defective disc





Disc insertion error (for example, an upside±down disc)





No disc present

Disc Loading Tray



Tray for loading the disc. Eject the disc tray to insert or remove a





disc. The tray does not open if the drive power is off.

Emergency Eject



By inserting the end of a paper clip, you can eject the disc tray if





the workstation does not have power.
