TROUBLESHOOTING

pOSSIBLE PROBLEM	EASY SOLUTION
	• The safety locking arm may not be correctly engaged
	in the vertical operating position with the locking arm
	located into the two grooves on either side of the juice
	cover.
	• Check the Overload Protection Button on the bottom of
	the Motor Base to ensure the safety device has not been
	activated or the overheating protection device has not
	been activated automatically, if it has, allow more time
	for the motor to cool down.
Motor appears to stall	• Wet pulp can build up under the cover if the juicing
when juicing	action is too vigorous. Try a slower juicing action by
	pushing the food pusher down slower. Clean the Filter
	Bowl Surround, the Nutri Disc™ and the juicer cover.
	Select a faster speed for harder fruits and vegetables.
	• The Breville juicer will automatically stop operating if
	the motor is stalled. This is a electronic safety feature.
	Either too much food is being processed at one time
	or the pieces are not small enough. Try trimming food,
	cutting food into smaller pieces of even size and/or
	processing a smaller amount per batch. If this occurs,
	the light surrounding the StartStop button will flash
	red. To continue juicing, reset the Juicer by pressing
	the StartStop button to OFF, then clear the feed chute,
	finally turn the appliance back on by pressing the
	StartStop button to ON.
	• Hard fruits and vegetables will put excess strain onto
	the motor if a low speed is selected. Please refer to the
	juicing guide, to determine the correct speed for the
	fruits and vegetables selected on juicing.
Excess pulp building up	• Stop the juicing process. Remove the juicer cover and
in the mesh of the Nutri	remove the pulp. Re-assemble and begin juicing again.
Disc™	Try alternating (soft and hard) vegetable and
	fruit varieties.
Pulp too wet and reduced	• Try a slower juicing action. Remove Nutri Disc™ and
extracted juice	thoroughly clean mesh walls with the brush included.
	Rinse Nutri Disc™ under hot water. If the mesh holes are
	blocked, soak the Nutri Disc™ in a solution of hot water
	with 10% lemon juice to unblock the holes or wash in the
	dishwasher. This will remove excess fiber build up (from
	fruit or vegetables) which could be inhibiting the juice
	flow.
