Hamilton Beach 70570, 70579 How to Use Slicer/Shredder Disc, With Large Bowl only Speeds 1 or

Page 9

840174102 ENv01.qxd:Layout 1 8/26/10 8:18 AM Page 9

How to Use Slicer/Shredder Disc

(with Large Bowl only) (Speeds 1 or 2)

wWARNING Laceration Hazard. Handle blade carefully; it is very sharp.

Make sure control knob is turned to OFF (O) and unit is unplugged. NOTE: Operate using only one blade or disc at a time.

1

2

3

4A SMALLER, THINNER FOODS

Align large bowl and base. Turn large bowl clockwise to lock into place. NOTE: Unit will not work unless large bowl is locked.

Carefully place disc onto motor shaft with desired side facing UP.

Align lid and large bowl. Turn lid clockwise to lock into place. NOTE: Unit will not work unless lid is locked.

Close lid and push lid latch firmly to lock. NOTE: Unit will not work unless latch is locked.

SMALLER, THINNER FOODS

Put large food pusher into place. Place food into open tube of large food pusher.

OR

SMALLER, THINNER FOODS

4B

LARGER FOODS

Push small, thin food with small

Close lid and push lid latch firmly

food pusher. Never push food

to lock. NOTE: Unit will not work

through chute with fingers.

unless latch is locked.

LARGER FOODS

Push large foods using large and small food pushers together. Never push food through chute

with fingers.

9
