10CHAPTER 1: PRODUCT INTRODUCTION

Figure 5 Front panel of a Switch 4210 18-port PWR













































(1)

































































(2)

































(3)









(4)















































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































































(8)(7) (6) (5)

(1)

10/100Base-TX autosensing Ethernet port status LED



(2)

Link LED for Combo port

(3)

Console port

(4)

Power LED (PWR)

(5) A/L LED

(6)

D/S LED

(7)

Mode button

(8)

Active LED for Combo port





Rear panel

Figure 6 Rear panel of a Switch 4210 18-port PWR

(1)

(1) AC power socket

Side panel

Each Switch 4210 18-port PWR provides a security slot, through which you can lock the device together with an irremovable object to prevent theft. The security slot is located on the left side panel, as shown in Figure 7.
