Option | Description | |
|
| |
| Default Setting: Enable Intel SpeedStep | |
C States Control | Allows you to enable or disable the additional processor sleep states. | |
| Default Setting: The option C statesis enabled. | |
Intel® TurboBoost™ | Allows you to enable or disable the Intel TurboBoost mode of the processor. | |
| Default Setting: Enable Intel TurboBoost | |
Allows you to enable or disable the HyperThreading in the processor. | ||
| Default Setting: Enabled | |
Table 20. Power Management |
|
|
|
| |
Option | Description | |
|
| |
AC Behavior | Allows you to enable or disable the computer from turning on automatically when | |
| an AC adapter is connected. | |
| Default Setting: Wake on AC is not selected. | |
Auto On Time | Allows you to set the time at which the computer must turn on automatically. The | |
| options are: | |
| • | Disabled |
| • | Every Day |
| • | Weekdays |
| • | Select Days |
| Default Setting: Disabled | |
USB Wake Support | Allows you to enable USB devices to wake the system from Standby. | |
| NOTE: This feature is only functional when the AC power adapter is connected. | |
| If the AC power adapter is removed during Standby, the system setup will | |
| remove power from all of the USB ports to conserve battery power. | |
| • Enable USB Wake Support | |
| • Default Setting: Enable USB Wake Support is not selected | |
Wireless Radio Control | Allows you to enable or disable the feature that automatically switches from wired | |
| or wireless networks without depending on the physical connection. | |
| • | Control WLAN Radio |
| • | Control WWAN Radio |
| • Default Setting: Control WLAN radio or Control WWAN radio is not | |
|
| selected |
Wake on LAN/WLAN | Allows you to enable or disable the feature that powers on the computer from the | |
| Off state when triggered by a LAN signal. | |
| • Disabled: This option is enabled by default | |
| • | LAN Only |
| • | WLAN Only |
| • | LAN or WLAN |
64
