Maintenance and Cleaning
Cleaning the Air Filter
Air filter prevent dust from accumulating on the optical elements inside the projector. Should the air filter become clogged with dust particles, it will reduce cooling fans' effectiveness and may result in internal heat build up and adversely affect the life of the projector. Clean the air filter following the steps below.
1 Turn off the projector, and disconnect the AC power cord from the AC outlet.
2 | Remove the air filter by pulling the latch horizontally. |
3 | Clean the air filter with a brush or rinse it softly. |
4 When cleaning the air filter by rinsing, dry it well. Replace the air filter properly. Make sure that the air filter is fully inserted.
CAUTION
Do not operate the projector with the air filter removed. Dust may accumulate on the optical elements degrading picture quality.
Do not put anything into the air intake vent. It may result in malfunction of the projector.
RECOMMENDATION
W e r e c o m m e n d a v o i d i n g d u s t y / s m o k y environments when operating the projector.. Usage in these environments may cause a poor image quality..
When using the projector under dusty or smoky conditions, dust may accumulate on a lens, LCD panels, or optical elements inside the projector. This condition may degrade the quality of a projected image. When the symptoms above are noticed, contact your authorized dealer or service station for proper cleaning.
Attaching the Lens Cover
When moving this projector or while not using it over an extended period of time, replace the lens cover.
Attach the lens cover according to the following procedures.
1 | Pass the string through a hole of the lens cover. |
2 | Turn over the projector. |
3 | Attach the string with lens cover to the filter cover at |
| the bottom of the projector. |
Air filter
Pull horizontally and remove.
Lens Cover | String for the lens cover. |
|
58
