30
COOLING PERFORMANCE DATA GSZ130484A*
EXPANDED PERFORMANCE DATA
M ODEL: GS Z130484A* / AR*F486016** COOLING OP ERATION
Outd oo r Ambien t Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Te mpe r ature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 46.66 47.67 50.93 54.45 45.57 46.57 49.75 53.18 44.49 45.46 48.56 51.92 43.40 44.35 47.38 50.65 41.23 42.13 45.01 48.12 38.19 39.03 41.69 44.57
S/T 0.950.890.720.541.000.920.750.561.000.940.770.571.001.000.790.591.001.000.820.611.001.000.830.62
DT 23 22 19 15 23 22 19 15 23 22 19 15 22 23 19 15 21 22 19 15 20 20 18 14
1800 KW 3.29 3.36 3.46 3.56 3.53 3.60 3.71 3.82 3.74 3.81 3.93 4.05 3.92 4.00 4.12 4.25 4.07 4.16 4.29 4.42 4.21 4.30 4.43 4.57
AMPS 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.5 5.7 5.9 6.1 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8
HI PR 248 267 281 294 278 299 316 329 316 340 359 375 360 387 409 427 405 436 460 480 447 4 82 508 530
LO PR 1 09 116 127 135 116 123 134 143 120 128 139 1 48 126 134 146 156 132 141 153 163 137 1 45 159 169
MBh 45.346.349.552.944.245.248.351.643.244.147.250.442.143.146.0 49.2 40.0 40.9 43.7 46.7 37.1 37.9 40.5 43.3
S/T 0.900.850.690.510.940.880.710.530.960.900.730.550.990.930.76 0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59
DT 23 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 21 21 18 15
80 1600 KW 3.27 3.33 3.43 3.53 3.50 3.57 3.68 3.79 3.71 3.78 3.90 4.02 3.89 3.97 4.09 4.22 4.04 4.13 4.25 4.39 4.17 4.26 4.40 4.54
AMPS 4.5 4.6 4.7 4.9 4.8 4.9 5.0 5.2 5.2 5.3 5.5 5.6 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.7
HI PR 245 264 279 291 275 2 96 313 326 313 337 356 371 356 384 405 422 401 431 456 475 443 477 503 525
LO PR 1 08 115 126 134 114 122 133 141 119 126 138 1 47 125 133 145 154 131 139 152 162 135 144 157 167
MBh 41.842.745.648.840.841.744.647.739.940.743.546.538.939.742.545.436.937.840.343.134.235.037.439.9
S/T 0.870.820.660.500.900.850.690.510.920.870.710.530.950.900.730.540.990.930.760.571.000.940.760.57
DT 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 22 19 15
1400 KW 3.20 3.26 3.35 3.45 3.42 3.49 3.59 3.70 3.62 3.70 3.81 3.92 3.80 3.88 3.99 4.12 3.95 4.03 4.15 4.28 4.07 4.16 4.29 4.43
AMPS 4.4 4.4 4.6 4.7 4.7 4.8 4.9 5.1 5.0 5.2 5.3 5.5 5.4 5.5 5.7 5.8 5.7 5.8 6.0 6.2 6.0 6.1 6.3 6.6
HI PR 238 256 270 282 267 2 87 303 316 304 327 345 360 346 372 393 410 3 89 419 442 461 430 462 488 509
LO PR 1 05 112 122 130 111 118 129 137 115 123 134 1 43 121 129 141 150 127 135 147 157 131 1 40 152 162
MBh 47.47 48.39 50.68 54.07 46.37 47.26 49.50 52.81 45.26 46.14 48.32 51.55 44.16 45.01 47.14 50.29 41.95 42.76 44.79 47.78 38.86 39.61 41.49 44.26
S/T 0.990.960.860.701.000.990.900.731.001.000.920.741.001.000.950.771.001.000.980.801.001.000.990.80
DT 24 24 22 19 24 24 23 20 23 24 23 20 23 23 23 20 21 22 22 19 20 20 21 18
1800 KW 3.32 3.38 3.48 3.59 3.55 3.63 3.73 3.85 3.76 3.84 3.96 4.08 3.95 4.03 4.15 4.29 4.10 4.19 4.32 4.46 4.24 4.33 4.47 4.61
AMPS 4.5 4.6 4.8 4.9 4.9 5.0 5.1 5.3 5.3 5.4 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.8
HI PR 250 269 284 296 281 3 02 319 333 319 344 363 378 364 391 413 431 4 09 440 465 485 452 486 514 536
LO PR 1 10 117 128 137 117 124 135 144 121 129 141 1 50 127 135 148 158 133 142 155 165 138 1 47 160 171
MBh 46.147.049.252.545.045.948.151.343.944.846.950.142.943.745.848.840.741.543.546.437.738.540.343.0
S/T 0.950.910.820.670.980.950.850.691.000.970.880.711.001.000.900.731.001.000.940.761.001.000.950.77
DT 25 25 23 20 25 25 24 20 25 25 24 20 25 25 24 21 23 24 23 20 22 22 22 19
85 1600 KW 3.29 3.36 3.46 3.56 3.53 3.60 3.71 3.82 3.74 3.81 3.93 4.05 3.92 4.00 4.12 4.25 4.07 4.16 4.29 4.42 4.21 4.30 4.43 4.57
AMPS 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.5 5.7 5.9 6.1 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8
HI PR 248 267 281 294 278 2 99 316 329 316 340 359 375 360 387 409 427 4 05 436 460 480 447 482 508 530
LO PR 1 09 116 127 135 116 123 134 143 120 128 139 1 48 126 134 146 156 132 141 153 163 137 1 45 159 169
MBh 42.543.445.448.541.542.444.447.340.641.343.346.239.640.342.245.137.638.340.142.834.835.537.239.7
S/T 0.910.880.790.640.950.910.820.670.970.940.840.681.000.970.870.711.001.000.900.731.001.000.910.74
DT 25 25 24 21 26 25 24 21 26 25 24 21 26 26 24 21 25 25 24 21 23 23 22 19
1400 KW 3.22 3.28 3.38 3.48 3.45 3.52 3.62 3.73 3.65 3.72 3.84 3.95 3.83 3.91 4.02 4.15 3.98 4.06 4.19 4.32 4.11 4.19 4.32 4.46
AMPS 4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.1 5.1 5.2 5.4 5.5 5.4 5.5 5.7 5.9 5.7 5.9 6.0 6.3 6.0 6.2 6.4 6.6
HI PR 240 259 273 285 270 2 90 306 319 307 330 348 363 349 376 397 414 3 93 423 446 466 434 467 493 514
LO PR 1 06 113 123 131 112 119 130 139 116 124 135 1 44 122 130 142 151 128 136 149 159 133 1 41 154 164
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total sy stem pow er A MPS=outdoor unit amps ( comp.+fan)
High and low pre ssures are measured at the liquid and suction ser vice valves.
