DMA I/O address map

Table 34. DMA I/O address map

Address (hex)	Description	Bits	Byte pointer
0000	Channel 0, Memory Address register	00–15	Yes
0001	Channel 0, Transfer Count register	00–15	Yes
0002	Channel 1, Memory Address register	00–15	Yes
0003	Channel 1, Transfer Count register	00–15	Yes
0004	Channel 2, Memory Address register	00–15	Yes
0005	Channel 2, Transfer Count register	00–15	Yes
0006	Channel 3, Memory Address register	00–15	Yes
0007	Channel 3, Transfer Count register	00–15	Yes
0008	Channels 0–3, Read Status/Write Command	00–07
	register
0009	Channels 0–3, Write Request register	00–02
000A	Channels 0–3, Write Single Mask register bits	00–02
000B	Channels, 0–3, Mode register (write)	00–07
000C	Channels 0–3, Clear byte pointer (write)	N/A
000D	Channels, 0–3, Master clear (writer)/temp (read)	00–07
000E	Channels 0–3, Clear Mask register (write)	00–03
000F	Channels 0–3, Write All Mask register bits	00–03
0081	Channel 2, Page Table Address register	00–07
0082	Channel 3, Page Table Address register	00–07
0083	Channel 1, Page Table Address register	00–07
0087	Channel 0, Page Table Address register	00–07
0089	Channel 6, Page Table Address register	00–07
008A	Channel 7, Page Table Address register	00–07
008B	Channel 5, Page Table Address register	00–07
008F	Channel 4, Page Table Address/Refresh register	00–07
00C0	Channel 4, Memory Address register	00–15	Yes
00C2	Channel 4, Transfer Count register	00–15	Yes
00C4	Channel 5, Memory Address register	00–15	Yes
00C6	Channel 5, Transfer Count register	00–15	Yes
00C8	Channel 6, Memory Address register	00–15	Yes
00CA	Channel 6, Transfer Count register	00–15	Yes
00CC	Channel 7, Memory Address register	00–15	Yes
