Page 77

Resident Fonts

Resident Fonts

Print Quality	Available Fonts
Letter Quality	Courier, Gothic, Orator, Prestige,
	Roman, Swiss, Swiss Bold

Utility	Gothic

Bar Codes

•Code 39

•UPC A, UPC E

•EAN 8, EAN 13

•Interleaved 2 of 5

•Code 128

•Postnet

Resident Typefaces

Mode/Font	Size: Style
LQ Courier	10 & 12 cpi: Normal, Superscript, Subscript
	Proportional: Normal, Superscript, Subscript
	8 point: Normal
	Scalable: 11 to 64 points

LQ Letter	10 cpi, 12 cpi, Proportional: Normal
Gothic

LQ Prestige	10 cpi, 12 cpi, Proportional: Normal

LQ Orator	10 cpi, 12 cpi, Proportional: Normal

LQ Roman	10 & 12 cpi: Normal, Superscript, Subscript
	Proportional & 8 point: Normal
	Scalable: 11 to 64 points

LQ Swiss	10 & 12 cpi: Normal, Superscript, Subscript
	Proportional & 8 point: Normal
	Scalable: 11 to 64 points

LQ Swiss Bold	10 cpi, 12 cpi, Proportional: Normal

Utility Gothic	10 & 12 cpi: Normal, Superscript, Subscript

HSD Gothic	10 cpi: Normal

Specifications 77

Image 77
