Electronic Program Guide (EPG) (for DTV Only)

10

5Press / to select the D-VHS recorder model, and then press ENTER.

EPG



******

*******

10:00 PM – 11:30 PM



*******





*******





Reservation Setting

Program View

Program Rec

Recording Type

ANALOG

i.LINK

Device



D–VHS1

• A dialog box for confirmation appears.

6Press / to select “OK”, and then press ENTER.

The program is preset and the schedule table is restored.

A red square icon appears for the preset program.

A black icon appears for overlapped presetttings.

7Press DTV GUIDE to exit the Program Guide.

Switch on the recording equipment at least 30 seconds before the start of the preset program; otherwise recording will not be executed.

Recording is not executed if recordable D-VHS tape is not present in the D-VHS recorder when the preset program starts. This is also true when a D-VHS recorder specified for recording with a timer is not in connection.

Finish presetting operations two minutes before the start of the program; otherwise presettings may fail.

For priorities about overlapped presettings, see “Priority rules for overlapped presettings” on page 63.

If you switch off the system using the POWER button, the program presetting will become ineffective. Be careful not to switch off the power.

Recording TV programs via a VCR controller

If you connect an appropriate VCR controller to the Media Receiver, you can preset digital TV programs for recording with a connected VCR. See page 78.

1Press DTV GUIDE.

The EPG screen appears.

2Press / and / to select a program to be preset, and then press ENTER.

A setup menu appears.

EPG

******

*******

8:30 PM – 10:00 PM

*******



*******



Reservation Setting

Program View

Program Rec

3Press / to select “Program Rec”, and then press ENTER.

EPG

******

*******

8:30 PM – 10:00 PM

*******



*******



Reservation Setting

Program View

Program Rec

• A dialog box for mode selection appears.

61

En

PDP-ELITE-Eng (57-64)

61

9/9/03, 11:46

Page 61
Image 61
