Codabar Length 1, Length 2 Programming Instructions

Codabar

1.Scan the START bar code.

2.Scan either the Set Length 1 or Set Length 2 bar code.

3.Turn to Appendix C, Alpha-Numeric Pad and scan the three digits (zero padded) represent- ing the length in decimal notation.

For Codabar bar codes, all start, stop, check and data characters are included in the length calculations.

NOTE

4. Scan the END bar code.

START / END

PROGRAMMING BAR CODES

Set Length 1

Set Length 2

Quiet Zones

This feature enable/disables the requirement that quiet zones must be present for Codabar bar codes.

START / END

PROGRAMMING BAR CODES

Don’t require Quiet Zones

DEFAULT

Require Quiet Zones

Product Reference Guide

5-49
