Symbologies

Micro PDF417 — continued

Micro PDF417 Length 1, Length 2 Programming Instructions

1.Scan the START bar code.

2.Scan either the Set Length 1 or Set Length 2 bar code.

3.Turn to Appendix C, Alpha-Numeric Pad and scan the three digits (zero padded) represent- ing the length in decimal notation.

NOTE

Length 2 is the maximum label length if in vari- able length mode, or the second fixed length if in fixed length mode. Length includes the bar code’s check and data characters.

4. Scan the END bar code.

START / END

PROGRAMMING BAR CODES

Set Length 1

DEFAULT SETTING FOR THIS FEATURE: 001

Set Length 2

DEFAULT SETTING FOR THIS FEATURE: 366

5-76 Magellan® 1400i
